PVC Advertising Foam Sheet Line

Get a Price/Quote

MOQ : 1 Set

PVC Advertising Foam Sheet Line Specification

Motor Power
22 kW (Main Motor)

Model No
PVC-FSL-1400

Features
High Output, Energy Saving, Stable Running, Easy Maintenance

Control System
PLC Automatic Control

Noise Level
80 dB

Accuracy
0.1 mm

Power Rating
Three Phase, 75 kW

Machine Type
PVC Advertising Foam Sheet Line

Connectivity Options
HMI Touch Interface, Ethernet Compatible

Lubricating System
Automatic Lubrication

Operating Temperature
0C ~ 45C

Cooling System
Water Cooling System

Drive
AC Inverter Drive

Frame Type
Heavy Duty Steel Frame

Frequency
50 Hz

Voltage
380 V

Production Capacity
500-700 kg/hr

Plastic Processed
PVC

Product Type
Other

Technology
Extrusion Technology

Power Source
Electricity

Operating Type
Automatic

Power
75 kW

Pressure
High Precision Controlled

Surface Treatment
Smooth/Glossy Finish

Dimension (L*W*H)
23000 x 2500 x 2800 mm

Weight (kg)
7500 kg

Color
White/Grey/Custom

Usage & Applications
Industrial

Sheet Width
1220 mm-2050 mm

Heating Zones
6-8 Zones Separate Control

Sheet Thickness Range
2-18 mm

Feeding System
Automatic Doser and Hopper Loader

Extruder Type
Twin Screw Extruder

Vacuum Pump Power
7.5 kW

Screw Diameter
80/156 mm

Max. Sheet Length
Customizable

Roller Material
Chrome-Plated Alloy Steel

PVC Advertising Foam Sheet Line Trade Information

Minimum Order Quantity
1 Set

Supply Ability
100 Sets, , Per Month

Delivery Time
15 Days

Main Export Market(s)
Asia, Australia, Central America, North America, South America, Eastern Europe, Western Europe, Middle East, Africa

About PVC Advertising Foam Sheet Line

Reserve your Fanlyplas PVC Advertising Foam Sheet Line now and enjoy instant savings on this hot-selling, high-precision industrial solution. Designed with pristine craftsmanship and renowned for its brilliant output, this machine features customizable sheet widths, exacting thickness control (2-18mm), and a famed twin screw extruder. The fully automatic feeding, PLC control, and Ethernet connectivity ensure seamless operation. Engineered for high output and energy saving, every sheet achieves a smooth, glossy finish on a heavy-duty steel frame. Truly a magnificent choice for distributors, exporters, and industrial applications.

Competitive Edge and Machine Features

Fanlyplas PVC Advertising Foam Sheet Line stands out competitively with its advanced extrusion technology, legendary for delivering high output (500700 kg/hr) and impeccable precision (0.1 mm). Used extensively in signmaking, display panels, and commercial advertising, it supports a range of sheet configurations and thicknesses, producing both mono and multi-layer boards. The robust PLC automatic system, automatic dosing, hopper loader, and AC inverter drive make this foam sheet line a reliable, low-maintenance, and energy-efficient addition for industrial-scale manufacturers.

Packing, Logistics, and Export Information

Packing & Dispatch operations for the PVC Advertising Foam Sheet Line are streamlined for global orders, ensuring secure, efficient handling. FOB Port options include major Chinese seaports with flexible proposal amounts and payment terms tailored for international buyers. Fanlyplas excels in logistics, serving Main Export Markets like Europe, Asia, and the Middle East. With prompt dispatch and careful packing, clients receive their machines in pristine condition, safeguarding your investment throughout the supply chain.

Product details

Brand	Fanlyplas
Material	PVC dry blends
Product thickness	15-80mm
Product width	50-300mm
Output	100kg/h-500kg/h
Layer configuration	Mono layer,multi layer
Screw Design	Conical/parallel Twin screw
Line speed	0.5-6m/min

FAQs of PVC Advertising Foam Sheet Line:

Q: How does the PVC Advertising Foam Sheet Line ensure high precision in sheet production?

A: The line uses PLC automatic control, separate vacuum-pump-controlled heating zones, and advanced twin screw extrusion to maintain 0.1 mm thickness accuracy, guaranteeing consistently precise sheets.

Q: What are the primary commercial applications for the PVC Advertising Foam Sheet Line?

A: This machine is widely used in the advertising industry for producing rigid PVC sheets ideal for display panels, signboards, exhibition stands, and other commercial signage requirements.

Q: When can I expect the machine to be packed and dispatched after order placement?

A: Upon order confirmation and completion of payment terms, the packing and dispatch process typically initiates within a standard lead time, ensuring efficient shipment from the selected FOB port in China.

Q: Where is the PVC Advertising Foam Sheet Line predominantly exported to?

A: Fanlyplas primarily exports this line to global markets including Europe, Asia, and the Middle East, with logistical support for seamless delivery to clients worldwide.

Q: What are the advantages of the automatic dosing and feeding system?

A: The automatic doser and hopper loader enhance operational efficiency, minimize manual intervention, and ensure a stable, continuous production process for optimal output.
