Steel Coil Coating Line

Get a Price/Quote

MOQ : 1 Set

Steel Coil Coating Line Specification

Lubricating System
Automatic

Model No
SCCL-3800

Frame Type
Heavy Duty, Rigid Frame Structure

Machine Type
Automatic Coating Line

Accuracy
0.1 mm

Production Capacity
Up to 360 Tons/Day

Connectivity Options
HMI Touch Panel, Remote Monitoring (Optional)

Drive
AC Motor with Frequency Conversion

Noise Level
75 dB

Features
High Efficiency, Uniform Coating, Low Maintenance

Power Rating
Heavy Duty, 3 Phase

Cooling System
Water Cooled or Air Cooled

Frequency
50/60 Hz

Operating Temperature
0C-40C

Motor Power
30-90 kW

Control System
PLC Control System

Voltage
380 V / 415 V

Product Type
Coating Line

Technology
Continuous Coating Technology

Power Source
Electricity

Operating Type
Automatic

Power
120-300 kW (customizable)

Pressure
0.6-0.8 MPa

Surface Treatment
Pre-painted, Galvanized, and Customized Coating

Dimension (L*W*H)
38000 mm x 4500 mm x 6000 mm

Weight (kg)
Approximated 45000 kg

Color
As per customer requirement

Usage & Applications
Industrial

Steel Coil Coating Line Trade Information

Minimum Order Quantity
1 Set

Supply Ability
100 Sets Per Month

Delivery Time
15 Days

Main Export Market(s)
Central America, South America, Asia, Australia, Western Europe, Middle East, Eastern Europe, North America, Africa

About Steel Coil Coating Line

Steel Coil Coating Line we deal in is a coating line which includes the process as well as collection of several equipment and apply an organic coating to metal coil surface. The said line is offered with a web unwind or feed section. Our production line brings many profits for several businesses. This production line boasts of continuous operation, high efficacy, and advanced level of operation. Steel Coil Coating Line supplied by us is accessible with innovative operation.

Advanced Coating Flexibility

The SCCL-3800 steel coil coating line supports a wide range of coil sizes and coating materials, offering customizable thickness, coating type, and speedy output. Its technology ensures uniform, high-quality finishes suitable for pre-painted, galvanized, or custom-coated steel, enhancing product versatility for industrial clients.

Safety & Efficiency Built-In

Equipped with overload protection, emergency stop systems, and safety interlocks, the line prioritizes operator safety. Its automatic lubricating and stacking systems reduce manual interventions, while power saving features lower operating costs and enhance production efficiency.

Comprehensive Support & Connectivity

Our solution includes on-site installation and commissioning by expert engineers. The intuitive HMI touch panel and optional remote monitoring allow seamless operation and diagnostics, ensuring maximum uptime and simplified control for manufacturers, distributors, and suppliers.

FAQs of Steel Coil Coating Line:

Q: How does the SCCL-3800 coating line adjust to different material specifications?

A: The SCCL-3800 offers adjustable line speed, accommodating material thicknesses from 0.15 to 1.2 mm and widths between 600 to 1500 mm. Its PLC control system enables fine-tuning for various materials such as CR, HR, GI, GL, PPGI, and PPGL, ensuring compatibility and consistent results.

Q: What is the coating process used in this line, and what types of coatings can be applied?

A: This line employs a continuous coating technology using hot air circulation, gas, or electric ovens. It supports customizable coating thickness (530m) and a variety of coating types, including Polyester, SMP, PVDF, PU, and Epoxy, covering a wide spectrum of finishing requirements.

Q: When is on-site installation and commissioning provided?

A: On-site installation and commissioning are arranged as part of our support services. After purchase, a trained engineering team arrives at your facility, overseeing hardware setup, system integration, and initial operational training to ensure smooth startup.

Q: Where can this steel coil coating line be effectively used?

A: Designed for industrial environments, the SCCL-3800 is suitable for steel product manufacturers, distributors, exporters, and suppliers. Its robust frame and high production capacity make it ideal for plants specializing in pre-painted, galvanized, and custom-coated steel.

Q: What benefits does the automatic stacking and lubrication system offer?

A: The automatic stacking system streamlines packing, reducing manual handling and improving throughput. The automatic lubrication system ensures consistent maintenance, minimizing downtime and extending equipment longevity for efficient production cycles.

Q: How does the control system enhance operational efficiency?

A: The advanced PLC system, HMI touch panel, and optional remote monitoring facilitate intuitive process management, precise adjustments, and real-time monitoring. This results in reduced errors, increased accuracy (0.1 mm), and greater productivity.
